Aztec QR code reader in metal housing, desktop, CMOS HD201

GTIN: 5905669434294 SKU: HD201 Category:
  • Type of scanned codes: 1D and 2D barcodes including QR and Aztec, from paper labels and phone screens
  • Scanning sensor: CMOS matrix
  • Form factor: stationary / desktop (hands-free)
  • Housing material: metal
  • Scanning mode: manual / automatic (on code approach)
  • Available interfaces: USB or RS232 (Virtual COM supported)
  • Set includes: scanner, communication cable, user manual

263.76(214.44 net)

Out of stock

Product availability
Secure payment
Secure payments
Pay quickly online and shop safely with Stripe Accepted payment methods
Shipping and returns
+ Satisfaction guarantee
Returnable within 30 days
Stationary scanner icon

Discover the HD201 scanner for all conditions with a metal casing

The HD201 stationary barcode scanner is made from high-quality materials and features a solid metal casing, making it durable and resistant to falls. It is perfectly suited for use in challenging environments such as warehouses or production halls. The scanner also integrates seamlessly with fiscal cash registers, making it equally suitable for stores and boutiques. The HD201 is available in two versions to choose from: with USB or RS232 cable. Browse more wired barcode scanners in our offer.

HD201 stationary QR code scanner with metal housing

QR and Aztec code scanning icon

Precise and accurate code reading

The scanning system, meticulously crafted from high-quality components, effortlessly reads leading 1D and 2D barcodes, including the Aztec code found in vehicle registration documents. Additionally, it can easily read codes from LCD and LED/OLED screens as well as displays of mobile devices. A notable feature of the scanner is the ability to program a prefix and suffix if needed.

HD201 reading Aztec code from vehicle registration

Compact design icon

Minimalism and modern design

The HD201 features a small, compact shape that allows you to save workspace. Its attractive, modern design ensures the equipment blends seamlessly into any interior, enhancing the aesthetics of the environment. Automatic scanning mode means codes are read as soon as they are presented to the sensor – hands-free operation perfect for fixed-position applications such as POS counters and reception desks.

HD201 stationary Aztec QR scanner in metal casing

Set includes icon

The set includes:

Wired HD201 barcode reader, USB cable, user manual.

HD201 set contents

Specification

  • Scanning engine: CMOS
  • Scanning method: automatically (after approaching the code), manually (push button)
  • Built-in memory: No
  • Interface: USB, Virtual COM
  • Reader stand: No
  • Codes being read: 1D (line), 2D (multidimensional)
  • Docking station: No
  • Reading codes from the LCD screen: Yes
  • USB Receiver: No
  • Long Range: No
  • Cable length: 200 cm
  • Current consumption: 250 mA
  • Housing: metal
  • Light source: laser LED 630nm +/- 10nm
  • Operating humidity: 5 to 95%
  • Operating temperature: 0 to 45°C
  • Package dimensions: 27,5 x 18 x 10 cm
  • Print contrast: min 25%
  • Readable 1D codes: CODABAR, CODE 11, CODE 128, CODE 32, CODE 39, CODE 93, GS1 Composite+, GS1 DataBar, HongKong 2 z 5, IATA 2 z 5, Interleaved 2 of 5 (ITF), Matrix 2 z 5, microPDF, MSI Plessey, NEC 2 z 5, Pharmacode Plessey, Telepen, Straight 2 z 5, Trioptic, UPC/EAN/JAN
  • Readable 2D codes: Aztec, DataMatrix (ECC 200), GoCode, HanXin, MaxiCode, microQR, QR Code
  • Storage temperature: -20 to 70°C
  • Dimensions of the device: 7 x 5 x 2,6 cm
  • Device Weight: 280 g
  • Weight with packaging: 360 g

Frequently asked questions

Can the HD201 read Aztec codes from vehicle registration documents?

Yes. The HD201 reads 1D and 2D barcodes including Aztec codes found in vehicle registration documents, as well as QR, Data Matrix, PDF417 and standard 1D codes.

What makes the metal housing important?

The solid metal casing provides high mechanical durability and resistance to falls, dust and accidental impacts. This makes the HD201 suitable for harsh environments such as warehouses, workshops and production halls where plastic devices would not last.

Which interfaces does the HD201 support?

The HD201 is available in two versions: with a USB cable (works as HID keyboard, also supports Virtual COM) or with an RS232 cable, allowing integration with legacy POS systems and industrial equipment.
