RFID reader for access control for 13.56 MHz proximity cards, Wiegand 26/34, DC 12V, compact SecureEntry-CR60HF

SKU: SecureEntry-CR60HF
  • Verification type: RFID card
  • Frequency of operation: 13,56 MHz
  • Operating voltage: DC 9V - 16V, standard 12V
  • Interface: Wiegand 26 lub 34

Secure access to the building with compact SecureEntry-CR60HF

The SecureEntry-CR60HF is a stylish and compact RFID access control reader that combines elegance with functionality. Made of durable zinc alloy, the reader features a robust design for reliability. It is ideal as an access control device for various rooms in companies, offices and institutions, offering effective protection and an elegant technological solution.

RFID reader for 13.56 MHz access control SecureEntry-CR60HF

Security is the key

The SecureEntry-CR60HF model offers DC 9V – 16V and operates at 13.56 MHz. Verification is done by approaching an RFID card. The reader can be combined with an electronic or electromagnetic lock, allowing convenient and secure door unlocking. In addition, the SecureEntry-CR60HF is equipped with a Wiegand 26 interface, which can be changed to Wiegand 34.

Access control reader for RFID cards by HDWR company

The set includes:

RFID access control reader, connecting cables, special key, user manual.

Access control SecureEntry-CR60HF proximity card RFID reader from HDWR

Frequently asked questions

Specifications

Warranty

1 year

Fabrication material

zinc alloy

Device type

RFID reader with access control

Frequency of operation

13,56 MHz

Verification type

RFID card

Speed of response

less than 0.2 seconds

Reading distance

2-10 cm, depending on the card or tag

Access control

yes

Light signal

two-color LED

Sound signal

built-in speaker (buzzer)

Communication distance

100 meters

Data transfer

in real time

Operating voltage

DC 9V – 16V, standard 12V

Operating current

70mA

Interface

Wiegand 26 or 34

Operating temperature

-25º C – 75º C

Operating humidity

10%-90%

Product dimensions

8.6 x 8.6 x 8.2 cm

Package dimensions

10,5 x 9,6 x 3 cm

Product weight

100 g

Product weight with packaging

250 g
