UHF RFID tag 865-868 MHz resistant to high temperatures, read range 140-270 cm Tag-H4-2019

Specification

• Color: Black
• Material: metal
• Suitable surface: metal surfaces
• Frequency of operation: EU 865-868 MHz, US 902-928 MHz
• Reading distance: Up to 140 cm (handheld reader), up to 270 cm (stationary reader)
• IC type: Alien Higgs-4
• Memory: EPC 128 bits, USER 128 bits, TID 64 bits
• Write cycles: 100,000 times
• Data storage: up to 50 years
• Dimensions of the device: 20 x 2.1 mm
• Holes: 2 mm x 2
• Weight: 10 g
• Operating temperature: -40°C to +150°C (10 hours of operation at 180°C)
• Storage temperature: -55°C to +200°C (280°C for 50 minutes, 250°C for 150 minutes)
• Protection class: IP68
• Certificates: Approved range, Approved RoHS, Approved CE
